FastShip Service available for our most popular LEWA ecoflow®pumps
within North America.

Your reliable partner provides another first class service for customers with short-term demands: LEWA-Nikkiso America now offers two weeks shipment on selected LEWA ecoflow pumps.

Improvements and advantages:

  • Pumps that historically had a lead time of 8-10 weeks are now available in 2 weeks
  • Pricing and options immediately available here
  • No expediting fees for quick delivery

Contact us at 1-508-429-7403  |  LewaFastshiplewa-inccom

As a reliable partner we do listen to our partner's needs:

We now provide another first class service for customers with short-term demands.

To meet the requirements of our customers, LEWA-Nikkiso America now offers two weeks shipment on selected LEWA ecoflow pumps:



LEWA ecoflow | Type LDB

  • PMax psiG discharge: 1160 (low pressure head)
  • Max flow (gph): 124
  • Max temperature: 302o F





LEWA ecoflow | Type LDC

  • PMax psiG discharge: 5800
  • Max flow (gph): 99
  • Max temperature: 302o F


Program Details | Terms and Conditions

Terms: LNA standard terms and conditions

  • Warranty: 12 months from start-up or 18 months from shipment, whichever occurs first
  • Net 30 days payment
  • FOB Holliston, MA

How to order

  • The pump part numbers in the program do not have any special identifiers that are required to be included in the order.
  • Orders can be accepted via hard copy, e-mail or telephone
  • All orders are final and non-cancellable, non returnable
  • Pump quantity 1 to 2 ships within 10 working days
  • Pump quantity 3+ ships at standard lead time

Additional specifications are limited to Pump Documentation:

  • Simplex pumps only
  • No customer approvals allowed
  • M9 double diaphragm head (316/316L/PTFE)
  • General arrangement drawing: Single ball check valves


Data package consists of:

  • Horizontal configuration


Pump data sheet

  • TEFC motor standard (limited options – see motor notes)
  • Installation and operating manual
  • Standard industrial purpose design

Selection and model specifications

For further details such as pricing, dampers download our order sheet here.



Plunger Diameter Pmax psiG max gph@139 spm Req'd Suc. Pres.
psiA@139 spm		 Connections NPT-F Single Ball Check Valve Motor HP Ordering Number
LDB Specifications@ 139 spm
8 1160 1,45 0,7 1/4" Ceramic Oxide 0,50 FSB-08-139
12 1160 3,41 1,03 1/4" Ceramic Oxide 0,50 FSB-12-139
17 1160 6,6 1,9 1/4" Ceramic Oxide 0,50 FSB-17-139
25 551 14,46 0,91 1/2" Ceramic Oxide 0,50 FSB-25-139
30 371 21,68 1,16 1/2 Ceramic Oxide 0,50 FSB-30-139
42 170 43 1,31 3/4" Ceramic Oxide 0,50 FSB-42-139
58 70 82,77 2,41 3/4" Ceramic Oxide 0,50 FSB-58-139



Plunger Diameter Pmax psiG max gph@208 spm Req'd Suc. Pres.
psiA@139 spm		 Connections NPT-F Single Ball Check Valve Motor HP Ordering Number
LDB Specifications@ 208 spm
8 1160 2,18 0,8 1/4" Ceramic Oxide 0,50 FSB-08-208
12 1160 5,12 1,58 1/4" Ceramic Oxide 0,50 FSB-12-208
17 1160 9,9 3,46 1/4" Ceramic Oxide 0,75 FSB-17-208
25 551 21,6 1,33 1/2" Stainless Steel 0,75 FSB-25-208
30 371 32,53 1,88 1/2 Stainless Steel 0,75 FSB-30-208
42 170 64,53 1,80 3/4" Stainless Steel 0,75 FSB-42-208
58 70 124,21 4,58 3/4" Stainless Steel 0,75 FSB-58-208



Plunger Diameter Pmax psiG max gph@208 spm Req'd Suc. Pres.
psiA@139 spm		 Connections NPT-F Single Ball Check Valve Motor HP Ordering Number
LDC Specifications@ 139 spm
8 5800 1,16 0,7 1/4" Ceramic Oxide 0,50 FSC-08-140
12 5800 2,98 1,04 1/4" Ceramic Oxide 0,75 FSC-12-140
17 3150 6,13 1,92 1/4" Ceramic Oxide 0,75 FSC-17-140
25 1437 13,75 0,91 1/2" Ceramic Oxide 0,75 FSC-25-140
38 600 34,64 1,18 3/4 Stainless Steel 0,75 FSC-38-140
52 302 65,93 1,9 3/4" Stainless Steel 0,75 FSC-52-140



Plunger Diameter Pmax psiG max gph@208 spm Req'd Suc. Pres.
psiA@139 spm		 Connections NPT-F Single Ball Check Valve Motor HP Ordering Number
LDC Specifications@ 208 spm
8 5800 1,75 0,81 1/4" Ceramic Oxide 0,50 FSC-08-210
12 5800 4,46 1,6 1/4" Ceramic Oxide 1,00 FSC-12-210
17 3150 9,19 3,51 1/4" Ceramic Oxide 1,00 FSC-17-210
25 1437 20,63 1,34 1/2" Ceramic Oxide 1,00 FSC-25-210
38 600 51,97 1,53 3/4 Stainless Steel 1,00 FSC-38-210
52 302 98,94 3,23 3/4" Stainless Steel 1,00 FSC-52-210
